Optoma HD710 - Disassemble Top Cover

HD71/HD710/HD75 Condential 2-2
2-2 Disassemble Top Cover
1. At “OPEN” mark,pull the Top Cover
to left side ( as yellow arrow)
2. Unscrew 5 screws
(as red circle)
3. Disassemble 1 FPC cable to
disassemble Top Cover
(as green square)
Note: There are 8 tenons
(as yellow circle)
