Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-2
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Top Cover 2-2
Disassemble Keypad Board,Keypad and FPC Cable 2-3
Disassemble Lamp Module 2-4
Disassemble I/O Cover 2-4
Disassemble Top Shielding 2-5
Disassemble Main Board Module,Audio Board Moudle and
Component Module 2-6
Disassemble Left Cover and Right Cover 2-7
Disassemble Fan Module 2-8
Disassemble LVPS Module 2-9
Disassemble Engine Module 2-10
Disassemble Thermal Switch,Blow Duct Rubber 2-11
Disassemble Color Wheel and Photo Sensor Board 2-12
Disassemble DMD Chip and DMD Board 2-13
Disassemble Zoom Ring 2-14
Disassemble Focus Ring 2-15
Disassemble ROD Module 2-16
Disassemble Blower Module 2-17
Disassemble Limit Switch 2-18
