HD71/HD710/HD75 Condential 2-7
2-8 Disassemble Left Cover
and Right Cover
1. Release 3 tenons on the left side
(as yellow square)
2. Disassemble Left Cover
3. Release 3 tenons on the right side
(as red square)
4. Disassemble Right Cover
