Optoma HD86 - Removing Optical Engine and Thermostat;C;W

Delta Elec. Inc. HD86
Company Confidential Optoma___________________ Delta________________
45
2009/08/18
Remove the Optical engine and Thermostat & C/W
Look the optical engine #2. Look the optical engine #3.
Remove these 2 screws (M3x8). Remove the screw (M3x8).
D
I
S
A
S
S
E
M
B
L
Y
Look the DMD chassis. Remove the screw (M3x8).
