4.2.5 HDMI-3 & DVI Inputs
 HDMI with or without HDCP, 36-bit video compatible.
 DVI-D input with or without HDCP
 Signal formats - video
o SD: 625i (576i) and 525i (480i) in double-rate formats;
o ED: 480p, 576p;
o HD: 1280x720p, 1920x1080i, 1920x1080psf; 1920x1080p 23.97, 24, 25, 29.94, 30, 50,
59.94 & 60Hz; 2048x1080p 23.97, 24, 25, 29.94, 30, 50, 59.94 & 60Hz.
 Signal formats – computer
o Common VESA graphics formats from VGA up-to 2560x1080p
4.2.6 HDMI-1 & HDMI-2 Inputs
 In addition to all signal formats supported by HDMI-3, these inputs also support 2560x1440p,
2560x1600p and 4K signals: 3840x2160p & 4096x2160p @ 23.97, 24, 25, 29.94, 30, 50, 59.94 &
60Hz (50, 59.94 & 60Hz supported in YUV 4:2:0 colour space format),
4.2.7 DP Input
 Display Port without HDCP, 36-bit video compatible.
 Signal formats as HDMI 1 and HDMI 2.
4.2.8 HDBT Input
 Uncompressed HD video over RJ45 connector and max.100m CAT5e cable (or better)
 CAT5e/CAT6 for 100m and signals with less than 225MHz Pixel Clock
 CAT6a/CAT7 for 100m and signals up to 297MHz Pixel Clock
 Signal formats as HDMI 1 and HDMI 2.
Graphics formats with odd numbered horizontal active pixels, e.g. 1365x768 are not supported.
