4-5
S310e/X312
3. Dark Pixel
Procedure - Test equipment: video generator.
- Test signal: analog 800x600@60Hz
- Test Pattern: full white
Inspection item - Dead pixels check.
Criteria - Please refer to Pixel specication table.
4. Bright Blemish
Procedure - Test equipment: video generator.
- Test signal: analog 800x600@60Hz
- Test Pattern: gray 10
Inspection item - Bright blemish check.
Criteria - Please refer to Pixel specication table.
5. Dark Blemish
Procedure - Test equipment: video generator.
- Test signal: analog 800x600@60Hz
- Test Pattern: blue 60
Inspection item - Dark blemish check
Criteria - Please refer to Pixel specication table.
Pixel specication
For X312
Order Symptom Pattern Criteria
1 Dark Blemish Blue 60
1. ≤ 4 visible dark blemishes
are allowed in the active area
2. No blemish will be > 1.5” long/
diameter
2 Light Blemish Gray 10
1. ≤ 4 visible light blemishes are
allowed in the active area
2. No blemish will be > 1.5” long/
diameter
3 Reset Boundary Artifact Gray 30
1. No reset boundary artifacts
allowed
Full white
Gray 10
Blue 60
