7. Disconnect the 8-pin modular cable and the RFID tag interface cable. The RFID
tag is factory-programmed with information specific to the workstation in which it is
installed. The RFID tag is bonded to the Workstation 6 casework; do not attempt to
remove it.
8. Loosen the five captive screws from the back of the unit.
9. Gently push the rear cover away from the power button.
10. Gently lift the rear cover.
Chapter 12
Disassembling the Workstation
12-5
