Oracle MICROS 6 Series - Reassembling the Workstation

Reassembling the Workstation
1. Place the rear cover over the system board and slide it toward the power button.
2. Tighten the screws to secure the rear cover.
3. Connect the RFID tag interface cable and the 8-pin modular cable for the magnetic
stripe reader.
Chapter 12
Reassembling the Workstation
12-6
