9. Tighten the screws on the brackets. (30 lb. torque)
10. Remove the spacer and confirm that the rails are attached tightly to the rack.
11. Stabilize the rack, using all anti-tilt mechanisms, to prevent it from tipping during
installation. See your rack documentation for detailed instructions.
Installing an Oracle ZFS Storage ZS5-2 Controller onto the
Rack Slide Rails
Use the following procedure to install an Oracle ZFS Storage ZS5-2 controller onto the
rack slide rails.
Caution:
This procedure requires a minimum of two people because of the weight of
the chassis. Attempting this procedure alone could result in equipment
damage or personal injury. Always load equipment into rack from the bottom
up.
1. If your rack includes an anti-tip foot, extend it from the bottom of the rack.
Chapter 7
Installing an Oracle ZFS Storage ZS5-2 Controller onto the Rack Slide Rails
7-4
