Powering On the Appliance
This section contains power-on procedures for Oracle ZFS Storage Appliance disk shelves
and storage controllers.
Caution:
Do not power on disk shelves and controllers until all other cabling is complete, as
described in Cabling the Appliance.
Follow these steps to power on the appliance:
1. Power on disk shelves using the appropriate procedure:
• Powering On an Oracle Storage Drive Enclosure DE3-24 or DE2-24 Disk Shelf
• Powering On a Sun Disk Shelf
2. Power on controllers. See Powering On a Controller.
Use the following procedures to power off the appliance:
• Powering Off a Controller
• Powering Off a Disk Shelf
Powering On an Oracle Storage Drive Enclosure DE3-24 or
DE2-24 Disk Shelf
Use the following procedure to power on an Oracle Storage Drive Enclosure DE3-24P,
DE3-24C, DE2-24P or DE2-24C disk shelf.
Before You Begin
Ensure you have met the following electrical safety measures before applying power to the
disk shelf:
• Provide a suitable power source with electrical overload protection to meet the power
supply input voltage range of 100-240 VAC, 50-60 Hz. The disk shelves are compatible
with 100-120 VAC or 200-240 VAC sources. The power source must not be overloaded
by the total number of disk shelves in the cabinet. At full load, each DE3-24 or DE2-24
draws 707.8W.
• The power source must provide a reliable earth connection for each disk shelf and the
cabinet.
• Ensure that the power source is easily accessible because the power cord is the main
disconnect device for the disk shelf.
1. Plug a power cord into each power supply with fan module.
2. Plug the other end of the power cords into the external power source for the cabinet.
12-1
