1 Power supply unit 0 status
LEDs OK: green Power
Supply Fail: amber AC OK:
green
2 Power supply unit 0 AC inlet 3 Power supply unit 1 status
LEDs OK: green Power
Supply Fail: amber AC OK:
green
4 Power supply unit 1 AC inlet 5 System status LEDs Power:
green Attention: amber
Locate: white
6 PCIe slots 0-4
7 Cluster card slot 8 Network (NET) 10/100/1000
ports: NET 0-NET 3
9 USB 2.0 ports
10 PCIe slots 5-9 11 Network management
(NET MGT) 10/100 BASE-T
Ethernet port
12 Serial management (SER
MGT) port
13 DB-15 video connector
Overview of the Sun ZFS Storage 7320 Controller
This section provides an overview of the Sun ZFS Storage 7320 controller. For
installation instructions, refer to Installing a Sun ZFS Storage 7x20 Controller. For
service instructions, refer to Servicing the 7x20 Controller in Oracle ZFS Storage
Appliance Customer Service Manual, Release OS8.8.x.
Sun ZFS Storage 7320 Electrical Specifications
The following list shows the electrical specifications for the Sun ZFS Storage 7320
controller.
Note:
The power dissipation numbers listed are the maximum rated power
numbers for the power supply. The numbers are not a rating of the actual
power consumption of the appliance.
Connectors
• Two C13 connectors, which work on 110-220v outlets
Input
• Nominal frequencies: 50/60Hz
• Nominal voltage range: 100-120/200-240 VAC
• Maximum current AC RMS: 9.0 amps Max
• AC operating range: 90-264 VAC
Output
• 3.3 VDC STBY: 3.6A
• +12 VDC: 62.3A
Power dissipation
Chapter 2
Overview of the Sun ZFS Storage 7320 Controller
2-54
