Installing an Oracle ZFS Storage ZS9-2
Controller
This section contains installation procedures for an Oracle ZFS Storage ZS9-2 controller.
Before beginning installation, see Installation Prerequisites and Hardware Overviews.
Use the following procedures to install an Oracle ZFS Storage ZS9-2 controller:
• Installing the Slide Rails onto an Oracle ZFS Storage ZS9-2 Controller
• Installing the Slide Rails into the Rack for an Oracle ZFS Storage ZS9-2 Controller
• Installing an Oracle ZFS Storage ZS9-2 Controller onto the Rack Slide Rails
• Installing an Oracle ZFS Storage ZS9-2 Cable Management Arm
• Verifying Operation of Oracle ZFS Storage ZS9-2 Slide-Rails and CMA
Installing the Slide Rails onto an Oracle ZFS Storage ZS9-2
Controller
Use the following procedure to install the slide rails onto an Oracle ZFS Storage ZS9-2
controller.
Note:
The slide rails can be used with either 9.5-mm square or M6 round mounting hole
racks.
1. Position a mounting bracket against the chassis so that the slide-rail lock is at the front of
the chassis, and the five keyhole openings on the mounting bracket are aligned with the
five locating pins on the side of the chassis.
Note:
The mounting brackets are identical and can be installed on either side of the
chassis.
4-1
