Oracle ZFS Storage ZS5-2 User Manual

1 Serial 1 2 Ethernet 3 Serial 0
4 Serial Link Status LED 5 Ethernet Link Status LED 6 Ethernet Activity LED
The following diagram illustrates the cluster serial and Ethernet ports for Oracle ZFS Storage
ZS3-2 controllers.
1
Serial Link Status LED 2 Ethernet 3 Serial 0
4 Serial 1 5 Ethernet Link Status LED 6 Ethernet Activity LED
Connecting Disk Shelf Cables
Use the following procedure to connect the cables between storage controller(s) and disk
shelves.
Chapter 11
Connecting Disk Shelf Cables
11-7

Oracle ZFS Storage ZS5-2 Specifications

General

Brand	Oracle
Model	ZFS Storage ZS5-2
Category	Storage device
