Overview of the Oracle ZFS Storage ZS5-2 Controller
This section provides an overview of the Oracle ZFS Storage ZS5-2 controller. For installation
instructions, refer to Installing an Oracle ZFS Storage ZS5-2 Controller. For service
instructions, refer to Servicing the ZS5-2 Controller in Oracle ZFS Storage Appliance
Customer Service Manual, Release OS8.8.x.
Refer to https://oracle.com/zfsstorage for the most recent component specification.
Oracle ZFS Storage ZS5-2 Physical Specifications
The Oracle ZFS Storage ZS5-2 controller chassis dimensions are as follows:
Dimension Measurement Dimension Measurement
Height 3.43 in./87.1 mm Depth 25.2 in./640.0 mm
Width 17.52 in./445 mm Weight 38.5 lb./17.5 kg
Oracle ZFS Storage ZS5-2 Electrical Specifications
The Oracle ZFS Storage ZS5-2 controller has two N+1 AC redundant hot-swappable AC
power supplies, rated 91% efficiency. To understand the overall power consumption, see
Oracle's online power calculator at http://www.oracle.com/goto/powercalculators .
Parameter AC Power Supplies
Nominal input frequencies 50/60 Hz
Operating input voltage range 100 VAC (Japan only)
110-127 VAC (90-132 range)
200-240 VAC (180-264 range)
Rated input current 10 A @ 100 VAC
9 A @110-127 VAC
5.5 A @ 200-240 VAC
Oracle ZFS Storage ZS5-2 Acoustic Noise Emissions
In compliance with the requirements defined in ISO 9296, the workplace-dependent noise
level of this product is less than 75 dBA.
Oracle ZFS Storage ZS5-2 Configuration Options
Oracle ZFS Storage ZS5-2 incorporates one or two controllers and one to sixteen disk
shelves. Each controller has six PCIe Gen3 slots. Each controller includes eight 2.5'' disk
slots that accommodate two system disks. Read cache devices are installed in disk shelves;
therefore, the remaining six disk slots have permanent filler panels. The following table
describes the configuration options.
Chapter 2
Overview of the Oracle ZFS Storage ZS5-2 Controller
2-37
