17. When securing the cables with the Velcro straps located on the front slide bar, ensure
that the Velcro straps do not wrap around the bottom of the slide bar.
Otherwise, expansion and contraction of the slide bar might be hindered when the server
is extended from the rack and returned to the rack.
18. Ensure that the secured cables do not extend above the top or below the bottom of the
server to which they are attached.
Otherwise, the cables might snag on other equipment installed in the rack when the
server is extended from the rack or returned to the rack.
19. If necessary, bundle the cables with additional Velcro straps to ensure that they stay clear
of other equipment.
Note:
If you need to install additional Velcro straps, wrap the straps around the cables
only, not around any of the CMA components; otherwise, expansion and
contraction of the CMA slide bars might be hindered when the server is
extended from the rack and returned to the rack.
Verifying Operation of the Oracle ZFS Storage ZS5-2 Slide-Rails
and CMA
Use the following procedure to verify the operation of the cable management arm (CMA) and
slide rails for an Oracle ZFS Storage ZS5-2 controller.
Before You Begin
Ensure all rack anti-tilt devices are extended to prevent the rack from tipping forward when
the storage controller is extended from the rack.
1. Slowly pull the storage controller out of the rack until the slide-rails reach their stops.
2. Inspect the attached cables for any binding or kinks.
3. Verify that the CMA extends fully with the slide-rails.
4. Push the storage controller back into the rack and verify that the CMA retracts without
binding.
5. Adjust the cable straps and the CMA, as required.
Chapter 7
Verifying Operation of the Oracle ZFS Storage ZS5-2 Slide-Rails and CMA
7-11
