How to Install a DE2-24P Disk Shelf
Caution - This procedure requires a minimum of two people, or a mechanical lift, because of
the weight of the chassis. Attempting this procedure alone could result in equipment damage or
personal injury. Always load the heaviest equipment (disk shelves) at the bottom of the rack.
Before You Begin
Extend all anti-tilt and stabilization devices from the bottom of the rack.
1.
If your rack is an unthreaded universal 19-inch or Sun Rack II cabinet:
a.
Position the front rail location pegs fully inside the appropriate holes in the
front of the rack.
The rail flange must be inside of the cabinet flange, and the rail label facing the inside of
the cabinet.
b.
Insert and tighten one screw through the front of the rack and into the top
hole in the rails.
c.
Adjust the rail lengths to fit, and position the rear rail location pegs in the
corresponding rear rack holes.
Installing Disk Shelves 63
