Hardware Overviews
Overview of 7320 Controller
This section provides an overview of the Oracle ZFS Storage 7320 controller. For installation
instructions, refer to “Installing a 7x20 Controller” on page 99. For service instructions,
refer to the Oracle ZFS Storage Appliance Customer Service Manual.
7320 Electrical Specifications
The following list shows the electrical specifications for the 7320 controller.
Note - The power dissipation numbers listed are the maximum rated power numbers for the
power supply. The numbers are not a rating of the actual power consumption of the appliance.
Connectors
■
Two C13 connectors, which work on 110-220v outlets
Input
■
Nominal frequencies: 50/60Hz
■
Nominal voltage range: 100-120/200-240 VAC
■
Maximum current AC RMS: 9.0 amps Max
■
AC operating range: 90-264 VAC
Output
■
3.3 VDC STBY: 3.6A
■
+12 VDC: 62.3A
Power dissipation
■
Max power consumption: 873 W
■
Max heat output: 2977 BTU/hr
■
Volt-Ampere rating: 891 VA @ 240 VAC, 0.98P.F.
7320 Base Configurations
The 7320 controller base configuration options are:
Installation Prerequisites and Hardware Overviews 49
