Installing a ZS4-4 or ZS3-4 Controller
This section contains installation procedures for the ZS4-4 or ZS3-4 controller.
Before beginning installation, see “Installation Prerequisites and Hardware
Overviews” on page 11.
Use the following procedures to install a ZS4-4 or ZS3-4 controller:
■
“How to Install the Slide Rails onto a ZS4-4 or ZS3-4” on page 73
■
“How to Install the Slide Rails into the Rack for a ZS4-4 or ZS3-4” on page 74
■
“How to Install a ZS4-4 or ZS3-4 onto the Rack Slide Rails” on page 76
■
“How to Install a ZS4-4 or ZS3-4 Cable Management Arm” on page 78
How to Install the Slide Rails onto a ZS4-4 or ZS3-4
Use the following procedure to install the slide rails onto a ZS4-4 or ZS3-4 controller.
Note - The slide assembly mounting pins accommodate 9.5-mm square mounting holes. No
other mounting hole sizes are supported.
1.
Position a mounting bracket against the chassis so that the slide-rail lock is at
the front of the chassis, and the five keyed openings on the mounting bracket
are aligned with the five locating pins on the side of the chassis.
Installing a ZS4-4 or ZS3-4 Controller 73
