Preparation
−
5
−
2 Preparation
2.1 Checking the product
Verify that the items listed below are included.
Report any missing or damaged items to the branch or sales ofce from which you purchased the product.
Common to each type
□
Motor
....................................................
1
unit
With a gearhead for the combination type and geared type
□
Speed controller
..................................
1
unit
□
OPERATING MANUAL
(this document)
...................................
1
copy
□
QUICK START GUIDE
.......................
1
copy
□
Connection cable
................................
1
pc
Only for models supplied with the cable
□
Power supply cable [2 m (6.6 ft.)]
......
1
pc
Only for models supplied with the cable
A lead wire (green, 1 piece) for connecting the FG is included.
A plug is attached with only the cables for the single-
phase 100 VAC type.
The cables with a plug are for Japanese domestic
market only.
Supplied with models of the combination type and geared type
□
Hexagonal socket head screw set
....
1
set
Hexagonal socket head screw, at washer, spring washer,
4 pieces each
□
Parallel key
..........................................
1
pc
The hexagonal socket head screw set and parallel key are
enclosed in the same bag.
□
Safety cover
........................................
1
pc
Only for the hollow shaft type
2.2 How to identify the product model
US2 - 4 25 JA - GHR 50 - 3 N
Number: Length (m) of a supplied connection cable
1
: 1 m (3.3 ft.),
2
: 2 m (6.6 ft.),
3
: 3 m (9.8 ft.)
Blank: Without a supplied connection cable
Number: Gear ratio,
A: Round shaft type
Power supply voltage
JA: Single-phase 100 VAC, UA: Single-phase 110 VAC, 115 VAC
JC
: Single-phase 200 VAC,
EC
: Single-phase 220 VAC, 230 VAC
Output power
6
: 6 W,
15
: 15 W,
25
: 25 W,
40
: 40 W,
60
: 60 W,
90
: 90 W
Frame size
2: 60 mm (2.36 in.) sq., 3: 70 mm (2.76 in.) sq., 4: 80 mm (3.15 in.) sq., 5: 90 mm (3.54 in.) sq.
Series name
SCM 4 25 GV - JA
Power supply voltage
Pinion shaft type: GV, GVH, GVR
Round shaft type: A
Output power
Frame size
Speed control motor for a motor and speed controller package
4 GV 50 B
Pinion type
Frame size
Gear ratio
Identification code
US2 D 25 - JA B
Identification code
Output power
For US2 Series
Power supply voltage
Gear type Blank: Parallel shaft∙round shaft,
GHR: Hollow shaft, GAR: Solid shaft (Right shaft), GAL: Solid shaft (Left shaft)
Speed controller
SCM 4 25 JA - GHR 50
Gear ratio
Gear type
Power supply voltage
Output power
Frame size of the motor
Speed control motor for a motor and speed controller package
Blank: With a supplied power-supply cable
N䠖 Without a supplied power-supply cable
Motor and speed controller package
Speed controller
GearheadMotor
(Parallel shaft·combination type, round shaft type)
Motor (Right angle·geared type)
