Preparation
−
6
−
2.3 List of combinations
Model names for motor, gearhead and speed controller are shown below.
•
Enter the gear ratio in the box (
o
) within the model name.
For the round shaft type, enter "
A
" in the box (
o
) within the model name of a motor and speed controller package.
Enter "
A
" instead of
GV
,
GVH
, or
GVR
within the model name of the motor.
•
Enter the cable length (
1
,
2
,
3
) in the box (
) within the model name when the connection cable is supplied.
•
Add "
N
" to the end of the model name when the power supply cable is not supplied.
Parallel shaft • combination type, round shaft type
Motor
output power
Power supply voltage Model Motor model
Gearhead
model
Speed controller
model
6 W
Single-phase 100 VAC
US2-26JA-
o
-
SCM26GV-JA
2GV
o
B
US2D6-JA
Single-phase 110/115 VAC
US2-26UA-
o
-
SCM26GV-UA US2D6-UA
Single-phase 200 VAC
US2-26JC-
o
-
SCM26GV-JC US2D6-JC
Single-phase 220/230 VAC
US2-26EC-
o
-
SCM26GV-EC US2D6-EC
15 W
Single-phase 100 VAC
US2-315JA-
o
-
SCM315GV-JA
3GV
o
B
US2D15-JA
Single-phase 110/115 VAC
US2-315UA-
o
-
SCM315GV-UA US2D15-UA
Single-phase 200 VAC
US2-315JC-
o
-
SCM315GV-JC US2D15-JC
Single-phase 220/230 VAC
US2-315EC-
o
-
SCM315GV-EC US2D15-EC
25 W
Single-phase 100 VAC
US2-425JA-
o
-
SCM425GV-JA
4GV
o
B
US2D25-JA
Single-phase 110/115 VAC
US2-425UA-
o
-
SCM425GV-UA US2D25-UA
Single-phase 200 VAC
US2-425JC-
o
-
SCM425GV-JC US2D25-JC
Single-phase 220/230 VAC
US2-425EC-
o
-
SCM425GV-EC US2D25-EC
40 W
Single-phase 100 VAC
US2-540JA-
o
-
SCM540GV-JA
5GV
o
B
US2D40-JA
Single-phase 110/115 VAC
US2-540UA-
o
-
SCM540GV-UA US2D40-UA
Single-phase 200 VAC
US2-540JC-
o
-
SCM540GV-JC US2D40-JC
Single-phase 220/230 VAC
US2-540EC-
o
-
SCM540GV-EC US2D40-EC
60 W
Single-phase 100 VAC
US2-560JA-
o
-
SCM560GVH-JA
5GVH
o
B
US2D60-JA
Single-phase 110/115 VAC
US2-560UA-
o
-
SCM560GVH-UA US2D60-UA
Single-phase 200 VAC
US2-560JC-
o
-
SCM560GVH-JC US2D60-JC
Single-phase 220/230 VAC
US2-560EC-
o
-
SCM560GVH-EC US2D60-EC
90 W
Single-phase 100 VAC
US2-590JA-
o
-
SCM590GVR-JA
5GVR
o
B
US2D90-JA
Single-phase 110/115 VAC
US2-590UA-
o
-
SCM590GVR-UA US2D90-UA
Single-phase 200 VAC
US2-590JC-
o
-
SCM590GVR-JC US2D90-JC
Single-phase 220/230 VAC
US2-590EC-
o
-
SCM590GVR-EC US2D90-EC
Right angle • geared type
Output shaft
type
Motor
output
power
Power supply voltage Model Motor model
Motor model
name for
CE marking
Speed
controller
model
Hollow shaft
25 W
Single-phase 100 VAC
US2-425JA-GHR
o
-
SCM425JA-GHR
o
SCM425HP-JA US2D25-JAB
Single-phase 200 VAC
US2-425JC-GHR
o
-
SCM425JC-GHR
o
SCM425HP-JC US2D25-JCB
40 W
Single-phase 100 VAC
US2-540JA-GHR
o
-
SCM540JA-GHR
o
SCM540HP-JA US2D40-JAB
Single-phase 200 VAC
US2-540JC-GHR
o
-
SCM540JC-GHR
o
SCM540HP-JC US2D40-JC
90 W
Single-phase 100 VAC
US2-590JA-GHR
o
-
SCM590JA-GHR
o
SCM590HP-JA US2D90-JA
Single-phase 200 VAC
US2-590JC-GHR
o
-
SCM590JC-GHR
o
SCM590HP-JC US2D90-JC
Solid shaft
(Right shaft)
25 W
Single-phase 100 VAC
US2-425JA-GAR
o
-
SCM425JA-GAR
o
SCM425HP-JA US2D25-JAB
Single-phase 200 VAC
US2-425JC-GAR
o
-
SCM425JC-GAR
o
SCM425HP-JC US2D25-JCB
40 W
Single-phase 100 VAC
US2-540JA-GAR
o
-
SCM540JA-GAR
o
SCM540HP-JA US2D40-JAB
Single-phase 200 VAC
US2-540JC-GAR
o
-
SCM540JC-GAR
o
SCM540HP-JC US2D40-JC
90 W
Single-phase 100 VAC
US2-590JA-GAR
o
-
SCM590JA-GAR
o
SCM590HP-JA US2D90-JA
Single-phase 200 VAC
US2-590JC-GAR
o
-
SCM590JC-GAR
o
SCM590HP-JC US2D90-JC
Solid shaft
(Left shaft)
25 W
Single-phase 100 VAC
US2-425JA-GAL
o
-
SCM425JA-GAL
o
SCM425HP-JA US2D25-JAB
Single-phase 200 VAC
US2-425JC-GAL
o
-
SCM425JC-GAL
o
SCM425HP-JC US2D25-JCB
40 W
Single-phase 100 VAC
US2-540JA-GAL
o
-
SCM540JA-GAL
o
SCM540HP-JA US2D40-JAB
Single-phase 200 VAC
US2-540JC-GAL
o
-
SCM540JC-GAL
o
SCM540HP-JC US2D40-JC
90 W
Single-phase 100 VAC
US2-590JA-GAL
o
-
SCM590JA-GAL
o
SCM590HP-JA US2D90-JA
Single-phase 200 VAC
US2-590JC-GAL
o
-
SCM590JC-GAL
o
SCM590HP-JC US2D90-JC
