Orion ODC-10000 User Manual

- 60 -
ORION PDP
- 61 -
Innitely Expandable
*IDrange(Program):0x01(1)~0xFF(255)
*CheckSum:Execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
*ElapsedTime
-Hundredthousands,tenthousands,thousands,hundreds,tens,ones:0(0x00)~9(0x09)rangevalue.

Command for assigning and identifying the serial numbers of each IP board. (8 digit) -
CMD: 0x75 (Get S/N), 0x76 (Set S/N)
Send to MLCD
-
STX CMD Length
Data
ETX
ID Master
Value 0x02 Variable 0x02 Variable 0X01 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*"Get/SetIPSerialNumber"(0x75/0x76)commandisnotapplicableas"Broad-cast"command,becauseeachLCDshouldhavean
uniqueserialnumber.
Receive from MLCD -
STX CMD Length
Data
Check
Sum
ETX
ID Master Elapsed Time
Value 0x02 Variable 0x0A Variable 0x01 … Variable 0x03
0 1st 2nd 3rd 4th 5th 6th 7th
Variable Variable Variable Variable Variable Variable Variable Variable
*IDrange(Program):0x01(1)~0xFF(255)  *M/S:Master(0x01),Slave(0x00)
*CheckSum:Execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
*ElapsedTime
-0,1st,2nd,3rd,4th,5th,6th,7th:0(0x00)~9(0x09)rangevalue

Command for obtain the current LCD (IP) information -
CMD: 0x87
-
It is available only on Power On (Operative) status.
-
Send to MLCD
-
STX CMD Length
Data
ETX
ID Master
Value 0x02 0x87 0x02 Variable 0X01 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*Itcannotbeusedas"Broad-cast"command.
Receive from MLCD -
STX CMD Length
Data
Check Sum ETX
ID Master Status
Value 0x02 0x87 0x23 Variable 0X01 … Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*CheckSum:Execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
*Status(32byte)
No. Data Length

1 PWR Status 1 byte
0:PowerOff(Stand-by),1:PowerOn(Working)
2 Input Source 1 byte
0x0C:PC,0x0E:DVI,0x0D:DTV,0x07:DVD,0x05:S-Video,0x02:Video
3 Resolution 1 byte
Thevalueof"DisplayedResolutionatthetimeofdetection"
4 Not Used
5 Global Offset 1 byte
0:GlobalOffsetOff,1:GlobalOffsetOn
6 Color Temp. 1 byte
0:Normalmode,1:Studiomode
7 Auto-Power Mode 1 byte
0:Auto-PowerOff,1:Auto-PowerOn
8 FAN Mode 1 byte
0:Auto,1:Full
9 Temperature0 1 byte
0(0x00): 0˚C~ 127(0x7F): 127˚C / 128(0x80): -1˚C ~ 254(0xFE): -127˚C
0xFF: Temp. Sensor Error
10 Temperature1 1 byte
0(0x00): 0˚C ~ 127(0x7F): 127˚C / 128(0x80): -1˚C ~ 254(0xFE): -127˚C
0xFF: Temp. Sensor Error
11 FAN Status 1 byte 0x30: Good, 0x31: Error
12~18 F/W Version 7 byte
Year:2byte,Month:2byte,Day:2byte,Rev.(0~9):1byte
Ex)December29th,2012Rev.2→0x010x020x010x020x020x090x02
19 Not Used
20~27 S/N 8 byte
123456 →0x000x000x010x020x030x040x050x06
1 →0x000x000x000x000x000x000x000x01
28~33 Elapsed Time 6 byte
54321 → 0x00 0x05 0x04 0x03 0x02 0x01
10 → 0x00 0x00 0x00 0x00 0x01 0x00
<DisplayedResolutionatthetimeofdetection(ItisdifferentfromthesupportingResolution)>
Resolution Value Resolution Value Resolution Value
640x480x60 0(0x00) 720Px50 29(0x1D) 1360x768x60 25(0x19)
640x480x85 1(0x01) 576Px50 30(0x1E) 640x350x85 46(0x2E)
800x600x56 2(0x02 )
480Px60 31(0x1F ) 640x480x75 47(0x2 F)
800x600x60 3(0x03) 1920x1080ix60 32(0x20) 640x480x72 48(0x30)
800x600x75 4(0x04)
1920x1080ix50 33(0x21) 1152x864x75 49(0x31)
800x600x85 5(0x05)
1280x720P x60 34(0x22) 1280x720x60 50(0x32)
853x480x60 6(0x06) 1280x720P x50 35(0x23)
1280x768x75 51(0x33)
1024x768x60 7(0x07) PAL 36(0x24) 1280x1024x75 52(0x34)
1024x768x70 8(0x08)
SECAM 37(0x25) 1366x768x50 53(0x35)
1024x768x75 9(0x09) PALP 38(0x26) 1400x1050x50 54(0x36)
1024x768x85 10(0x0A) NTSC 39(0x27) 1440x900x60 55(0x37)
1280x768x60 11( 0x 0B ) NTSCP 40(0x28) 576ix50 56(0x38)
1280x960x60 12(0x0C) Unknown 42(0x2A) 480ix60 57(0x39)
1280x1024x60 13(0x0D) No-Signal 43(0x2B) 1080px60 58(0x3A)
1366x768x60 14(0x0 E) 853x480x50 18(0x12) 1080px50 59(0x3B)
1600x1200x60 15(0x0F) 1280x1024x50 19(0x13) 1920x1080px60 60(0x3C)
1400x1050x60 16(0x10) 1360x768x50 20 (0 x14) 1920x1080px50 61(0x3D)
1706x960x60 17(0x11) 1600x900x50 21(0x15) 1024x576x50 62(0x3E)
1080ix60 26(0x1A) 1600x900x60 22(0x16) 1024x576x60 63(0x3F)
1080ix50 27(0x1B) 1600x1200x50 23( 0x17)
720Px60 28(0x1C) 800x600x50 24(0x18)
※Theresolutionswritteninredoritalicletterscanbedetected,buttheyarenotsupportingresolutions.
MLCD
