Osprey Talon front panel diagram
You should familiarize yourself with the front panel controls for the Osprey Talon. Besides the basic
buttons for power, start/stop, up/down and menu access, there are indicator lights that are hidden until
illuminated.
OSPREY TALON FRONT PANEL
A
Power On/Off
B
HDMI in
C
Composite in
D
Unbalanced Audio in
E
HD/SDI in
Osprey Talon back panel
diagram
A
1G Ethernet
B
Service
C
USB
D
9 – 17 VDC
