Otto Bock B400 - Operation; 6.1 Adjustment Possibilities

06/2011 B400Page 94
Operation
INFORMATION
Remove the fuse for shipping or when the power
wheelchair is not being used for an extended period of time.
6 Operation
6.1 AdjustmentPossibilities
CAUTION
Riskofinjuryduetounsecuredscrewconnections.Af-
ter loosening screw connections with thread lock, replace
these screw connections with new ones or secure them
with medium-strength thread lock substance (e.g. Eu-
roLock A24.20).
After the power wheelchair has been set and adjusted,
the attachment screws and/or nuts must be firmly retight-
ened. During tightening observe torques when specified.
Various adjustments can be made to the power wheelchair.
The seat height, seat width and seat angle have been set in
accordance with the indications on the customer order form
and may only be changed by the specialist dealer.
The following items can be adapted by the user:
n Back angle
n Armrest height
n Armrest position
n Lower leg length
If need be, the footrests and side panels can be removed.
6.1.1 Backrest
The backrest can be set to four different angles by pulling
the release strap at the base of the backrest (g. 6).
Once the backrest is in the desired position, release the
strap to engage the locks.
