Operation
Fig.6 Releasestrapforthebackrest
6.1.2 SidePanelwithArmrest
The side panels can be removed by loosening the thumb
screws and lifting the side panels. If the control panel is at-
tached to the armrest, the side panel must be removed to-
gether with the control panel and carefully deposited on the
ground or on the wheelchair seat.
The thumb screws are located at the lower end of the arm-
rest holders (see arrow, g. 7).
Fig.7 Removingthesidepanel
After remounting the side panel, do not forget to rmly
retighten the thumb screw.
The height of the armrest can be changed by loosening and
shifting the screw (see g. 8).
Firmly re-tighten the screws after making adjustments.
INFORMATION
The side panels must be inserted into the armrest
holder up to the height of the lowest receiver tube‘s bore
hole at least.
