Otto Bock B400 - 6.3.4 Battery Capacity LED Indicator

06/2011
B400
Page 103
Operation
AdaptingtheDrivingCharacteristics
WARNING
Riskofaccidentsandinjuryduetoincorrectconfigura-
tionsettings.Modied parameter settings in the congu-
ration can lead to changes in driving characteristics.
In particular, changes to the speed, acceleration, braking
or joystick settings can lead to unexpected and therefore
uncontrollable operating performance with a risk of acci-
dents.
Always test the driving characteristics of the power wheel-
chair after conguration / programming is complete.
Programming must only be completed by authorised per-
sonnel. Neither Otto Bock nor the control unit manufac-
turer are liable for damages caused by programming that
was not properly / professionally adapted to the abilities
of the wheelchair user.
A hand programming device, which is to be connected to
the control panel, can only be used by specialist dealer to
adapt the speed, acceleration and deceleration values to
the individual wishes of the user.
6.3.4 BatteryCapacityLEDIndicator
INFORMATION
Immediately after switching the power wheelchair on, the
battery indicator shows the battery capacity saved before
the wheelchair was switched off the last time. The exact
battery status is displayed after driving a short distance.
The battery indicator on the LED display consists of 10
segments and shows the remaining battery capacity (see
Table 2).
A charge of 100% corresponds to 10 full segments in LED
display. If one segment disappears, this means that the bat-
tery’s capacity has decreased by approximately 10%. At a
total range of approximately 35 km over even terrain, each
segment corresponds to a range of approximately 3.5 km
when the speed is kept constant.
If the last three segments ash, the battery must be charged
immediately.
The charging process is indicated by LED running light.
When the battery is charging, the driving function is blocked.
