3.3 Setting values
Changing a setting:
H1 (H2) Control circuit → H1 (H2) Setting values
The regulator has two types of setting values: those that are al-
ways visible and those than can only be changed using a service
code.
Both circuits (H1 and H2) have the same circuit-specific setting values.
H1 Control circuit
H1 Setting values
H1 Info
H1 Heating curve
H1 Setting values
H1 Control mode Automatic
Room temperature setting 21.5 °C
Temperature drop
Supply water min limit 12 °C
Supply water max limit 45 °C
>
>
>
>
>
>
>
>
Room temperature setting
21.5 °C
• Choose the desired setting by turning the control knob.
• Press OK to go to the view where editing is possible. Change
• the setting.
• Press OK to accept the change.
H1 (H2) Control circuit → H1 (H2) Setting values → Temperature drop
3.3.1 Temperature drop
Both heating circuits have the same circuit-specific settings
Send a message: H1 Settings.
The controller sends the main settings to your mobile
phone.
Editing the setting values: write the new setting in place
of the old setting and send a message back to the control-
ler. The controller sends the setting as a return message.
Key words:
H1 Setting values:
Room temperature = 21.5°C/
Temperature drop = 3.0°C/
H1 Setting values
H2 Setting values
H1 Setting values:
Room temperature = 21.5°C/
Temperature drop = 3.0°C/
Setting
Factory
setting
Range Explanation
Room temperature set-
ting
21.5 5... 35 °C Basic room temperature setting for the controller set by the user. This set-
ting value is not visible unless room compensation is in use. Taking it into
use is done from the “H1 (2) Setting values” → “Room temperature settings” .
Supply water min limit 12 5... 95 °C Minimum allowed supply water temperature. A higher minimum temperature
is used in damp rooms and tiled rooms than in, e.g., rooms having a parquet
floor to ensure a comfortable temperature and removal of moisture in the
summer.
Supply water max limit 45 5... 95 °C Maximum allowed supply water temperature. The maximum limit prevents the temp.
in the heating circuit from rising too high, preventing damage to pipes and surface
materials.
Summer function outdoor.
limit
19 10... 35°C Summer function outdoor temperature limit. When the measured outdoor tem-
perature exceeds the outdoor temperature limit of the summer function, the
valve will be closed and the circulation water pump will stop when summer func-
tion is ac-tive. When the summer function is active, the control mode is ”Summer
stop” in basic view.
Setting
Factory
setting
Range Explanation
Temperature drop or
Room temperature drop
0 0... 20 °C Temperature drop of supply water, which can start due to weekly schedule,
exception schedule, Home/Away switch, “Away” text message command or
when selecting “Away” as the Home/Away control status from the controller
(Inputs and outputs). If room temperature measurement has been taken into
use, the temperature drop is given directly as a room temperature drop.
Temp.drop Weekly
schedule
You can define a weekly schedule for temperature drops. More information on
the weekly schedule can be found from the next page.
Temp.drop Exception
schedule
Exception schedule is used for temperature drops which deviate from normal
weekly schedule. The exception schedule overrides always the weekly sched-
ule. More information can be found from the page 12.
Temperature drop
status
No drop No drop,
Away control.,
Time program,
Away control/
Time program
The Home/Away control and time program can changes the temperature
level.
