OUMAN H23 User Manual

4
Central factors related to the current heating control are shown in the Basic view. The Basic view will be
shown when the controller is in idle state (keys have not been touched for a while).
There are several dierent levels in H23’s user interface. The most significant measurement information in
regulation process’ view is shown in the Basic view.
1 USER INTERFACE
• A blinking exclamation
mark indicates active
alarms.
• The number of active
alarms is also shown.
Temperature measurements enable
quickly determining proper operation
of the circuit.
Control mode. This shows the current con-
trol of the circuit (auto/forced/manual) or
in summer mode (see p. 10).
Alarms
Deviation alarm
PRIO1 GROUP1
H1 Supply water=10.2 °C
Received: 08.01.2016 02:27
Press OK to acknowledge the alarm
Acknowledging alarms: Press OK and
the alarm sound will stop. If the reason
for the alarm has not been corrected,
the exclamation mark in the top right
will continue to blink.
Alarm indication
Outdoor temp.
H1 Supply water
H2 Supply water
DHW Supply water
Automatic
Automatic
Automatic
-12.4°C
45.2°C
32.8°C
58.0°C
13:51 25.01.2017
2
Selection>
1.1 Basic view
Ouman H23 can generate alarms for several dierent reasons. In the
event of an alarm, an alarm window pops up showing detailed alarm
information and a beeping alarm signal goes on.
If there are several unacknowledged alarms, the latest activated alarm
is always shown in the display. As soon as all active alarms have been
acknowledged, the alarm window disappears and the alarm signal goes
o.
Alarm signal of all active alarms may also be muted by pressing Esc
button. When you press Esc, the alarm signal stops and the last alarm
windows disappear from the display.
You may look into the alarms later by going to ”Alarms” > ”Active alarms”.
If an alarm has not been acknowledged, an exclamation mark will ap-
pear in the beginning of the row.
