We reserve the right to make changes to our products without a special notice.
OUMAN OY
ouman.
XM307_H23 User manual_ENG_V.2.0.0_20170323
32
TECHNICAL INFORMATION
Dimensions width 230 mm, height 160 mm, depth 60 mm
Weight 1.3 kg
Protection class IP 41
Operating temperature 0 ºC…+50 ºC
Storing temperature -20 ºC…+70 ºC
Power supply L (91), N (92)
Operating voltage 230 Vac / 200 mA
The internal 24 V power source, total load
capacity of max.
1A/23 VA
Supply cable fuse max 10A
Measurements inputs:
Sensor measurements (inputs 11-19) NTC10-element: ±0,15 ºC between -50 ºC…+100 ºC
Also sensor tolerances and the eect of cables must be
considered when calculating total accuracy.
Measurement M1 can be connected also from outside of the casing
by a plug-connector.
Digital inputs (27, 28) Contact voltage 15 Vdc,
switching current 5 mA
Transfer resistance max. 250 Ω (closed), min. 350 Ω (open).
Analog outputs
(66, 68, 70)
Output voltage range 0…10 V
Output current max. 10 mA / output
15 VDC output (1) 15 VDC output maximum load 100 mA
24 VAC output (51) Total current of 24 VAC output and triac-outputs max. 1A.
Pump control contacts (81-89) Contacts for three circulation pump
Pumps are controlled by a switches on the top of the H23 device
Relay max. load 3A.
Protective earth terminal (73-78) Protective earth terminal block for 230V devices. Control circuit
fuse max. 10A
Control outputs (51) 24 VAC -control output
Triac (55...60) Total current of triac-outputs and 24 VAC output max. 1A.
Data transfer connections
RS-485-bus A (3) and B (6) Unisolated, supported protocols Modbus-RTU.
Options
OULINK OULINK adapter provides Modbus TCP / IP interface for H23
device.
GSMMOD5 By connecting the GSM modem to the H23 , you can communi-
cate with the text messages to device and receive alarms
to GSM phone.
APPROVALS
EMC-directive
2014/30/EU, 93/68/EEC
Interference tolerance EN 61000-6-1
Interference emissions EN 61000-6-3
