OUMAN H23 User Manual

14
The H23 keeps the temperature of domestic hot water at the de-
signated setting value.
4 DOMESTIC HOT WATER
DHW Control circuit → DHW Info
Main menu
H1 Control circuit
H2 Control circuit
DHW Control circuit
Trend logs
>
>
>
>
4.1 DHW Info
Info-menu shows the domestic hot water settings, the measure-
ments and actuator control related to the domestic hot water.
DHW Info
Domestic hot water setting value 58.0 °C
Supply water 58.1 °C
Circulation water 59.0 °C
Actuator control 22 %
DHW Control circuit → DHW Trend display
4.2 Trend display
You can read the real-time trends of the temperatures of supply
water and circulation water. Also the real-time trend of actuator
control in domestic hot water circuit can be read. The sampling
interval is 1 s.
DHW Trend display
Supply water >
Circulation water >
Actuator control >
3.4 Control mode
H1 (H2) Control circuit → H1 (H2) Control mode
Automatic control is the mode that is used normally. You may
change automatic control to manual control here, and drive the
valve to the desired position.
H1 Control circuit
H1 Info
H1 Heating curve
H1 Setting
H1 Control mode Automatic
>
>
>
>
Control mode Explanation
Automatic
H23 controls the supply water temperature automatically according to the
need for heating and possible time programs (weekly schedule and holiday
calendar) or according to the home/away control.
Manual The actuator remains in the position defined in manual mode until the control
mode changed to automatic.
The actuators position in manual mode is changed with ”Actuator manual con-
trol” –setting. If 3-state actuator is in use, the direction of the control of the
valve is shown (open/close).If voltage controlled actuator is in use, the position
of the valve is shown as percent value.
Manual mech. (voltage controlled actuator) When the control mode is manual mechanic, the supply voltage from H23 to
actuator is cut and the position of the valve can be changed straight from the
actuator.
Control mode
Automatic
Manual electr.
Manual mech.
H1 Control mode
Control mode Manual electr.
Actuator manual control -
>
>
