Overkill Solar BMS Series User Manual

280 Ah pack: 224000
Full charge voltage (per cell)
3500
mV
End of discharge voltage (per cell)
2800
mV
Discharge rate
0.2
%
80% capacity voltage (per cell)
3400
mV
60% capacity voltage (per cell)
3300
mV
40% capacity voltage (per cell)
3200
mV
20% capacity voltage (per cell)
3100
mV


Protection parameters:
Parameter
Trigger Value
Release Value
Delay
(seconds)
Cell over voltage
3650 mV
3500 mV
2
Cell under voltage
2500 mV
3000 mV
2
Battery over voltage
29000 mV
28000 mV
2
Battery under voltage
20000 mV
24000 mV
2
Charge over current
110000 mA
32s
10
Discharge over current
110000 mA
32s
10
Charge over temp
65℃
55℃
2
Charge under temp
-1℃
5℃
2
Discharge over temp
75℃
70℃
2
Discharge under temp
-10℃
0℃
2



A.5: 24V Pack, 16 Cell, Using One 24V BMS
TBD
