Edge, or Video, as per the input signal
turn on the channel with signal input
been adjusted to the proper position
been adjusted to the proper division
been adjusted to the proper division
Run/Stop
To start or stop sampling on input signals.
Single Trigger
To set trigger mode in “Single”, under this trigger mode, when set condition met, the device will capture
the input signal once, then stop signal capturing.
xii. how to use socket connection
when the device communicates with PC by direct network cable
For the device, its default IP address / port goes in 192.168.1.172 / 8866.
When the device communicates with PC by direct network cable, the first 3 segments from the default IP
address of PC should read the same as those from the device, giving an example, both of 2 parties read
192.168.1.xxx (the last segment “xxx” could be different).
Note: The IP address of the device could not be modified before successfully communicating with PC.
i) to check target PC’s network setting
giving an example, here we set IP address in 192.168.1.71
