8. Technical Specifications
Performance Characteristics Instruction
100MHz ≤3.5ns (at input, Typical)
200MHz ≤1.75ns (at input, Typical)
300MHz ≤1.17ns (at input, Typical)
DC accuracy ±3%
DC accuracy
(average)
Average﹥16: ±(3% rdg + 0.05 div) for V△
Cursor V and T between cursors△△
Automatic
Vpp, Vmax, Vmin, Vtop, Vbase, Vamp,
Vavg, Vrms, Overshoot, Preshoot, Freq,
Period, Rise Time, Fall Time, DelayA→B ,
DelayA→B , +Width, -Width, +Duty, -Duty
Waveform Math ＋, －, *, / ,FFT
Waveform storage 15 waveforms
Bandw
idth
Full bandwidth
Measurement
Lissajous
figure
Phase
differe
nce
±3 degrees
Frequency ( typical) 1KHz square wave
Communication
port
USB2.0, USB for file storage, VGA port or RS-232
﹡Single channel is when only one input channel is working.
Trigger:
Performance Characteristics Instruction
Internal ±6 div from the screen center
EXT ±600mV
Trigger level range
EXT/5 ±3V
Internal ±0.3div Trigger level
Accuracy (typical)
EXT ±(40mV + 6% of Set Value)
User Manual of Smart Digital Storage Oscilloscope
