8. Technical Specifications
User Manual of Smart Digital Storage Oscilloscope
85
Performance Characteristics Instruction
EXT/5 ±(200mV +6% of Set Value)
Trigger
displacement
According to Record length and time base
Trigger Holdoff
range
100ns~10s
50% level
setting(typical)
Input signal frequency ≥50Hz
slope
Rising、Falling
Edge trigger
Sensitivity 0.3div
Trigger condition
Positive pulse：＞、＜、＝
negative pulse：＞、＜、＝ Pulse trigger
Pulse Width range 24ns～10s
Modulation
Support standard NTSC、PAL and
SECAM broadcast systems
Video Trigger
Line number range 1-525 (NTSC) and 1-625 (PAL/SECAM)
Trigger condition
Positive pulse：＞、＜、＝
negative pulse：＞、＜、＝ Slope Trigger
Time setting 24ns～10s
Trigger on CH1 Edge, Pulse, Video, Slope
Alternate Trigger
Trigger on CH2 Edge, Pulse, Video, Slope
