8. Technical Specifications
User Manual of Smart Digital Storage Oscilloscope
86
General Technical Specifications
Display
Display Type 8” Colored LCD (Liquid Crystal Display)
Display Resolution 800 (Horizontal) × 600 (Vertical) Pixels
Display Colors 65536 colors, TFT screen
Output of the Probe Compensator
Output Voltage
(Typical )
About 5V, with the Peak-to-Peak voltage equal to or greater
than 1MΩ of load.
Frequency (Typical ) Square wave of 1KHz
Power
Mains Voltage 100～240 VAC RMS, 50/60Hz, CAT II
Power Consumption < 18W
Fuse 1A, T grade, 250V
Battery (optional)
Cell:558792 4000mAh/3.7V
Pack:2s2p 7.4V/8000mAh
Environment
Temperature
Working temperature: 0 ℃～ 40 ℃
Storage temperature: -20 ℃～ +60 ℃
Relative Humidity ≤ 90%
Height
Operating: 3,000 m
Non-operating: 15,000 m
Cooling Method Natural convection
Mechanical Specifications
Dimension 340mm× 155mm×70mm （L*H*W）
Weight About 1.82 kilogram
Interval Period of Adjustment:
One year is recommended for the calibration interval period.
