4.User Notice
15
④
USB Device
interface
This configurable USB port permits
external USB devices. It supports
PictBridge printer and remote-control
connection.
⑤
External
trigger
connector
Connect an external TTL signal.
⑥
10MHz
IN/OUT
The BNC input or output of the 10 MHz
reference clock
⑦
LAN
interface
Through this interface, the analyzer can
be connected to your local network for
remote control.
⑧
Stool
To adjust the angle of the device
⑨
AC power
connector
AC: frequency 50Hz±10％, single-phase
alternative 220V±15％ or 110V±15％
