4.User Notice
9
4.4.1 Front Panel Function Key
Basic keys
Marker measure
Advanced
measure
Utility keysControl keys
Figure 4-2 Function Keys
Table 4-3 Function Key Description
Keys
Description
Basic keys
Activates the center-frequency function, and
accesses the frequency function menu.
NO.
Description
NO.
Description
①
LCD
⑦
Numeric keypad
②
Menu softkeys
⑧
Tracking generator
output connector
③
Function keys
⑨
Earphone interface
④
Knob
⑩
USB Host port
⑤
Arrow keys
⑪
Power key
(Push to turn on,
long push to turn off)
⑥
RF Input connector
FREQ
