5.10.3[External ►]
In this mode, an external signal (TTL signal) is input from the
[Trigger In] connector at the rear panel, its edge conditions should
meet with the user settings to generate trigger signals.
Press [External ►] to enter the submenu, and select [Positive
Edge] or [Negative Edge] as the trigger condition.
5.11 【TG】
When the Source is turned on, an independent signal or a signal
with the same frequency of the current sweep signal will be output
from the GEN OUTPUT 50Ω terminal on the front panel. Press the
key will pop out related menu includes [Track Gen On Off], [Output
Level], [Network Meas►]. The source is turned off in the power-on
and reset states.
5.11.1[Track Gen On Off]
Select the tracking generator to be on or off.
5.11.2 [Output Level]
Set the output power of CW or TG source.
5.11.3[Network Meas►]
When the source is “TG”, tracking source network measurement
function is available, mainly for amplitude and frequency
characteristics measurement; RF output and spectrum
measurement is fully synchronized, can be used as a scalar
network analyzer. When the network measurement function is "on",
the measurement results show relative values after "normalized",
expressed in "dB". When the network measurement function is
"off", the measurement shows the spectrum measurement result,
expressed in "dBm".
1) [Network Meas On Off]
Turn on or off the tracking source network measurement function.
