Pacific Power Source UPC-32 - Example of Program Query

SECTION 5 REMOTE OPERATION
92
5.7.2 EXAMPLE OF PROGRAM QUERY
Step A. Address the UPC as a listener
:PROGram:NAME 1 <eos>
Step B. Select Program 1
NOTE: <eos> is a LINE FEED (0Ahex, 10dec)
:PROGram:DEFine? <eos>
Step C. Query Program 1
Program 1 consists of steady-state and optional transient segment
parameter names and values. This Query returns steady-state values of
the selected program and segment values of the most recently selected
segment (see NOTE 1). "LAST" is returned with segment data if the
segment is the last segment in the program
Step D. Address the UPC as talker, read back the response string
NOTE: Only commas separate the values, NO Carriage Returns
or Line Feeds separate the values
STEADY-STATE OUTPUT PARAMETERS
returned
(Note: CURR:PROT:LEV and
CURR:PROT:TOUT are only
required if IPROT:STAT = ON)
NOTE: To query transient segment data (5.3.1), NSEGS
FORM,3,
COUPLing,DIRECT,
XFMRRATIO,1.0,
FREQuency,60,
VOLTage1,115,
VOLTage2,115,
VOLTage3,115,
CURRent:LIMit,10
CURRent:PROTect:LEVel,10
CURRent:PROTect:TOUT,1
PHASe2,120,
PHASe3,240,
WAVEFORM1,1,
WAVEFORM2,1,
WAVEFORM3,1,
EVENTS,0,
AUTORMS,1,
NSEGS,1,
OPTIONAL TRANSIENT PARAMETERS
returned
SEGment,1,
FSEG,60,
VSEG1,120,
VSEG2,120,
VSEG3,120,
WFSEG1,1,
WFSEG2,1,
WFSEG3,1,
TSEG,.01,
LAST<eos>
Step E. Un-address UPC
