SECTION 4 OPERATION
53
4.6 SETUP MODE
SETUP MODE is used to:
 Copy and Delete Programs
 Copy, Edit, and Create Waveforms
 Set Min. and Max. Voltage and Frequency Limits
 Enable and Disable CSC (Continuous Self Calibration)
 Set the Metering Sense Point – Internal or External
 Set Slew Rate and Transition Time
 Set Transformer Ratio
 Enable keyboard lockout
 Set initial power-on output voltage
 Monitor UPC and Power Source status
 View Firmware Version
 Enable Calibration Mode for Metering
 Adjust LCD View Angle and Backlight Intensity
 Set GPIB Device Address or Serial Interface Parameters
 Erase Memory
 Set Amps-to-Volts Current Metering Ratio
 Define Current Transformer Location
 Set Output Range - for power sources that support it
 Display the Number of Power Source Amplifiers
 Enable Current Protect Mode
 Synthesize Waveforms from Harmonic values (Option)
 Calibrate Programmable output impedance (Option)
 Enable and Set Programmable Output Impedance (Option)
From any meter display, press the fn key to enter SETUP MODE.
SETUP MENU: 1 PROGRAM
2 WAVEFORM
3 GENERAL
4 CALIBRATION
NOTE: Holding the fn key while applying power will bring up the SETUP MENU directly, with no Program
executing and no output. SETUP functions can be accessed as described below. Press CLEAR to exit
SETUP, the UPC will indicate “NO PROGRAM RUNNING”. Select a PROGRAM and EXECUTE to initiate
normal operation and display the V/I screen.
4.6.1 PROGRAM SETUP
PROGRAM SETUP is used to copy and delete programs and erase memory.
 From any METER display (V/I, AMPS or POWER), press the fn key to enter SETUP MODE.
 From the SETUP display, press 1 to enter PROGRAM SETUP.
PROGRAM MENU:
1 COPY PROGRAM
2 DELETE PROGRAM
3 INITIALIZE PROGRAMS, WAVEFORMS, SETUP
