Pacific Power Source UPC-32 - Metering Inputs

SECTION 2 SPECIFICATIONS
18
2.3.8 METERING INPUTS
Metering inputs are on J2. Common mode must be within ± 10 V
peak
with respect to power supply common.
J2
(Rear of SCU)
ФA CURRENT HI
1
ФA CURRENT LO
14
ФB CURRENT HI
2
ФB CURRENT LO
15
ФC CURRENT HI
3
ФC CURRENT LO
16
1Ф CURRENT LO
4
1Ф CURRENT HI
17
1Ф / ФA VOLTS HI
5
1Ф / ФA VOLTS LO
18
ФB VOLTS HI
6
ФB VOLTS LO
19
ФC VOLTS HI
7
ФC VOLTS LO
20
SPARE HI
8
SPARE LO
21
NO CONNECTION
9
LV COMMON
22
NO CONNECTION
10
LV COMMON
23
NO CONNECTION
11
LV COMMON
24
+15 V
12
LV COMMON
25
- 15 V
13
Figure 2.3.8 J2 METERING INPUTS
NOTE: J3 connector is accessible in UPC/SCU configuration
but is internal to any UPC equipped power source
