SECTION 4 OPERATION
55
4.6.1.3 INITIALIZE PROGRAMS, WAVEFORMS SETUP (continued)
WARNING: REMOVES ALL USER SETTINGS
PRESS "EXECUTE" TO INITIALIZE PROGRAMS
WAVEFORMS AND SETUP TO FACTORY DEFAULTS
PRESS "CLEAR" TO CANCEL
Press EXECUTE to initialize all programs, waveforms and setup to factory defaults.
Press CLEAR to cancel.
4.6.1.4 ERASE ALL RAM AND RESET CPU
If the programming has been corrupted and the UPC will not start properly, the system can be completely
reset by holding down the CLEAR key while applying INPUT POWER. This will clear ALL RAM (including
calibration data) and RESET the CPU.
NOTE: All Programs, Waveforms, and Calibration data will be erased when RAM is cleared.
4.6.2 WAVEFORM SETUP
WAVEFORM SETUP is used to copy and edit waveforms. OUTPUT ENABLE must be off before you can
change a waveform.
From any METER display (V/I, AMPS or POWER), press the fn key to enter SETUP MODE.
From the SETUP display, press 2 to enter WAVEFORM SETUP.
WAVEFORM MENU:
1 EDIT WAVEFORM
2 COPY WAVEFORM
3 WAVEFORM SYNTHESIS
4.6.2.1 EDIT WAVEFORM
EDIT WAVEFORM is used to change or modify waveforms.
From any METER display (V/I, AMPS or POWER), press the fn key to select SETUP MODE.
From the SETUP display, press 2 to enter WAVEFORM SETUP.
From the WAVEFORM SETUP display, press 1 to enter EDIT WAVEFORM.
EDIT WAVEFORM: NUMBER=16 RANGE=2-16
STARTING PHASE ANGLE =0 0-359.9°
ENDING PHASE ANGLE =0 0-359.9°
VOLTAGE IN PERCENT =-100 (+/-)0-100%
Press EXECUTE to save a new waveform.
The UPC will stop generating any output while the new waveform is being calculated.
