SECTION 5 REMOTE OPERATION
89
5.6.2 IEEE-488.2 DEVICE CONTROL COMMANDS
The following lists the IEEE-488.2 Common Commands for Device Control of the UPC. Refer to the
ANSI/IEEE-488.2 1987 standard for more information.
*RST
Command: RESET. Initialize the UPC with the following parameters
CSC:
OFF
CURRENT LIMIT:
CURRENT METERING RANGE
CURRENT PROTECT LEVEL:
CURRENT METERING RANGE
CURRENT PROTECT TIME:
1 (100 mSec)
CURRNT PROTECT STATE:
OFF
INITIAL VOLTAGE:
0
KEYBOARD LOCK:
OFF
MIN VOLTS:
0 V
MAX VOLTS:
600 V
MIN FREQUENCY:
45 Hz
MAX FREQUENCY:
5000 Hz
MODE:
MANUAL
OUTPUT:
DISABLED
OUTPUT COUPLING:
DIRECT
OUTPUT FORM:
1 or 3 (depending on model)
OUTPUT FREQUENCY:
60 Hz
OUTPUT VOLTAGE(S):
0
PHASE ANGLE B:
120°
PHASE ANGLE C:
240°
PROG. Zo:
OFF
RANGE CONTROL:
AUTO
SENSE:
INTERNAL
TRANSITION TIME:
0
WAVEFORM ФA:
1
WAVEFORM ФB:
1
WAVEFORM ФC:
1
NOTE: Stored programs are not erased
*TST?
Query: Self test. Test validity of non-volatile RAM
Returns 0 if no error
*WAI
Command: Wait-to-continue. Only useful following the :PROG:EXEC:TRANS or
*TRG commands. All other commands are executed sequentially as the Program
Message is parsed
*TRG
Command: IEEE-488.2 Device trigger function. Executes Transient Events (if
any), of currently executed program
*LLO
Command: LOCAL LOCKOUT. Puts the UPC into REMOTE mode and disables
local operation of the UPC keyboard
*GTL
Command: GOTO LOCAL. Enables local operation of the UPC keyboard
*DCL
Command: DEVICE CLEAR. Performs a hardware RESET of the UPC
