SECTION 5 REMOTE OPERATION
72
5.3.1 STEADY-STATE OUTPUT PARAMETERS (continued)
EVENTS,<n>
sets number of times to repeat the transient portion of the selected
program when the Transient is executed.
n = 0-65535. A value of 0 specifies continuous operation.
AUTORMS,<n>
program Transient Waveform Auto RMS mode (4.5.2).
n = 0, use program steady-state waveform RMS factor
n = 1, calculate RMS factor based on transient waveform
NSEGS,<n>
Command: Specifies the number of Transient segments (all
parameters) to return in a subsequent :PROG:DEFine? query. If
NSEGS is not specified, 1 segment is returned by :PROG:DEFine?
EXAMPLE: :PROG:DEF SEG,3,NSEGS,4;PROG:DEF? will return 4
transient segments, starting with Segment 3.
NOTE: The value will revert back to 1 after each query.
Query: The NSEGS parameter of a :PROG:DEF? query returns
total number of Transient segments defined in the selected program
5.3.2 TRANSIENT SEGMENT PARAMETERS
SEGment,<n>
Transient segment n of the selected program to be edited. Also the
starting segment when querying multiple segments (see NSEGS)
n = <1> to <100>
FSEG,<n>
sets objective Frequency of selected segment
n = <:SOUR:FREQ:LIM:MIN> to <:SOUR:FREQ:LIM:MAX> Hz
VSEG,<n>
sets objective voltage ФA, ФB, ФC of selected segment
n = <0> to <150, or 150 x XFMRRATIO> Volts
VSEG1,<n>
sets objective voltage ФA of selected segment
n = <0> to <150, or 150 x XFMRRATIO> Volts
VSEG2,<n>
sets objective voltage ФB of selected segment
n = <0> to <150, or 150 x XFMRRATIO> Volts
VSEG3,<n>
sets objective voltage ФC of selected segment
n = <0> to <150, or 150 x XFMRRATIO> Volts
WFSEG,<n>
sets Waveform ФA, ФB, ФC of selected segment
n = <1> to <16>
WFSEG1,<n>
sets Waveform ФA of selected segment
n = <1> to <16>
WFSEG2,<n>
sets Waveform ФB of selected segment
n = <1> to <16>
WFSEG3,<n>
sets Waveform ФC of selected segment
n = <1> to <16>
