SECTION 5 REMOTE OPERATION
77
5.4.3 WAVEFORM CONTROL
:PROGRAM:NAME <WFnn>
selects waveform “nn” for loading or data query
nn = 2 to 16 for data defining (loading) or 1 to 32 for data
query
:PROGram:[SELected:]DEFine <data>
loads selected waveform (2-16) with data from the Remote
Bus. The number of data elements must be 1024,
representing 0-359.7 degrees in 0.3512° steps. Each element
is a signed percentage of peak full scale voltage and may
have a maximum of 2 decimal digits. Each element must be
separated by a comma
NOTE: Only commas may separate the values, NO Carriage
Returns or Line Feeds may separate the values
e.g., <0,+5.23,+10,-50,+20,+25.7,+30,-43.91,+100>
5.5 QUERY FUNCTIONS
The following are 'query only' functions sent to the UPC through the communication bus.
5.5.1 CONFIGURATION QUERIES
These query parameters are set via DIP switches within the UPC, not via bus communication. The values
are specific to the hardware configuration of the individual power source.
:[SOURce]:XFMRRATIO?
Query: Output XFMR ratio
Returns <0.01> to <5.11> (3.4.1)
:[SOURce]:AVR?
Query: Current transformer AMPS:VOLTS ratio
Returns <1> to <511> (3.4.2)
:[SOURce]:CTLOC?
Query: Current transformer location
Returns <1> (PRIMARY) or <0> (SECONDARY) (3.4.4)
:[SOURce]:AMPLIFIERS?
Query: Number of installed power amplifiers in Power Source (3.4.4)
:SENSe:CURRent:RANGe?
Query: AMPS meter range
Returns <0> to <AMPS meter range> RMS Amps
