SECTION 5 REMOTE OPERATION
78
5.5.2 METERED DATA QUERIES
Measurement occurs once per :MEASure: command. AC measurements are assumed.
 The SCPI :AC keyword following :MEASure is optional and is not shown here.
 The “?” is optional as :MEASure: implies a query. Values following a command are ignored.
 'Multiple keyword' queries may be performed to obtain values of simultaneous measurements. e.g.,
:MEASure:VOLTage1;VOLTage2;VOLTage3?
:MEASure:VOLTage1?
Query: metered voltage ФA
Returns <0> to <354> VAC RMS
:MEASure:VOLTage2?
Query: metered voltage ФB
Returns <0> to <354> VAC RMS
:MEASure:VOLTage3?
Query: metered voltage ФC
Returns <0> to <354> VAC RMS
:MEASure:VLL1?
Query: metered Line to Line voltage ФA to ФB
Returns <0> to <354> VAC RMS
:MEASure:VLL2?
Query: metered Line to Line voltage ФB to ФC
Returns <0> to <354> VAC RMS
:MEASure:VLL3?
Query: metered Line to Line voltage ФC to ФA
Returns <0> to <354> VAC RMS
:MEASure:FREQuency?
Query: for programmed Frequency value
Returns <20.00> to <5000> Hz
The UPC reports only the programmed value, it does not measure
frequency
:MEASure:CURRent[:RMS]1?
Query: metered RMS current ФA
Returns <0> to <current meter range> AAC RMS
:MEASure:CURRent[:RMS]2?
Query: metered RMS current ФB
Returns <0> to <current meter range> AAC RMS
:MEASure:CURRent[:RMS]3?
Query: metered RMS current ФC
Returns <0> to <current meter range> AAC RMS
:MEASure:CURRent:PEAK1?
Query: metered peak current ФA
Returns <0> to <current meter range> A Peak
:MEASure:CURRent:PEAK2?
Query: metered peak current ФB
Returns <0> to <current meter range> A Peak
:MEASure:CURRent:PEAK3?
Query: metered peak current ФC
Returns <0> to <current meter range> A Peak
