SECTION 4 OPERATION
63
4.6.3.2 LIQUID CRYSTAL DISPLAY SETUP
LIQUID CRYSTAL DISPLAY SETUP is used to set the view angle and back light intensity and is accessed
from the General Setup menu (fn,3,2).
LIQUID CRYSTAL DISPLAY SETUP: PRESS
1 FOR VIEW ANGLE,
2 FOR BACK LIGHT,
THEN USE ARROWS TO ADJUST.
VIEW ANGLE: Press 1 then use the arrow keys to adjust the view angle of the LCD as desired.
BACK LIGHT: Press 2 then use the arrow keys to adjust the back light of the LCD as desired.
4.6.3.3 UPC STATUS
UPC STATUS indicates firmware part-number and version, GPIB or SERIAL interface status, DIP switch
settings and other system settings such as GPIB device address. See Section 10 if the SERIAL REMOTE
INTERFACE is installed. The UPC SETUP menu is accessed from the General Setup menu (fn,3,1). The
firmware part-number will vary depending on the features implemented (e.g. Prog Zo, HAS, etc.).
The UPC STATUS menu is accessed from the General Setup menu (fn,3,3).
For systems equipped with a GPIB (IEEE-488) communication port, the display will be:
UPC STATUS: FIRMWARE 133863 v5.00
GPIB ADDRESS 1 IFC LAST DATA BYTE=00h
TRANSFORMER RATIO 2.00 PAs=3
AMPS:VOLTS RATIO 4.00A=1 V PRI
If your UPC is configured with a serial port interface the UPC STATUS screen is:
UPC STATUS: FIRMWARE 133863 v5.00
BAUD:19200 PARITY:NONE LAST BYTE=00h
TRANSFORMER RATIO 2.00 PAs=3
AMPS:VOLTS RATIO 4.00A=1 V PRI EOS=CR/LF
To change any of these settings, press ENTER to move the cursor to each data field. Press EDIT when the
cursor is positioned on the value to be changed. Type the new value, then press ENTER to continue editing
or STORE to save and exit.
GPIB ADDRESS: 0 to 30. This is the IEEE-488 device address for the UPC. To change the
address, press EDIT, enter a valid number then press ENTER or STORE. The
factory default address is 1.
IFC: “Interface Clear”. This is displayed only if an IEEE-488 Interface Clear message is
received while this status display is shown. This display latches the IFC message.
Press CLEAR to clear this display and the IFC field. It is used for troubleshooting
the GPIB interface.
LAST DATA BYTE= This field displays the last data byte (DAB) received. The byte is shown in
hexadecimal format. Hex 0D (Carriage Return) is displayed as Hex 0A (New Line).
This is used for troubleshooting the GPIB interface.
