SECTION 4 OPERATION
65
4.6.3.5 RANGE CONTROL (continued)
RANGE CONTROL MODE: AUTO, MANUAL. AUTO is the default mode. Range is selected by the
UPC. Press the +/- key when the cursor is in the MODE field to toggle
between AUTO and MANUAL. When MANUAL MODE is selected, an
OUTPUT RANGE may be set.
SELECT OUTPUT RANGE: 1, 2, 3, 4. The following ranges are applicable.
PROGRAMMED OUTPUT AC VOLTS
NOTE: Voltages are for Single phase operation. If 2-phase operation is
used, the listed Output voltage ranges are doubled.
Press EXECUTE to save the parameter entries.
4.6.3.6 SLEW RATE SETUP
SLEW RATE SETUP allows the arrow key (︿ or ﹀) functions to transition at a predetermined rate and is
accessed from the General Setup menu (fn,3,6).
SLEW RATE SETUP:
VOLTS / SEC. = 1.00
HERTZ / SEC. = 1.00
Press EXECUTE to save the parameter entries. Default values are 1.00 volt/second and 1.00 Hz/second
NOTE: Slew rates are approximate.
4.6.3.7 INITIAL VOLTAGE
INITIAL VOLTAGE SETUP allows you to specify the initial power up output voltage amplitude and is
accessed from the General Setup menu (fn,3,7,1).
INITIAL VOLTAGE SETUP:
VOLTAGE=0
(Press +/- Key to Toggle Selection)
(Press ENTER or EXECUTE to Exit)
VOLTAGE=: 0 or LAST EXECUTED.
0: The output voltage at power-on is set at 0 volts. This is the default setting.
LAST EXECUTED: The output voltage at power-on is what it was prior to turning the unit off.
The output relay will always be open at power-up unless an “Auto-Start” option has been installed.
