SECTION 5 REMOTE OPERATION
74
5.4.1 OUTPUT PARAMETERS (continued)
*TRG
Same as :PROGram:EXECute:TRANS
:[SOURce:]VOLTage <n>
sets Output VOLTAGE amplitude of all available Phases
n = <0> to <150, or 150 x XFMRRATIO> Volts
:[SOURce:]VOLTage1 <n>
sets Output VOLTAGE ФA
n = <0> to <150, or 150 x XFMRRATIO> Volts
:[SOURce:]VOLTage2 <n>
sets Output VOLTAGE ФB
n = <0> to <150, or 150 x XFMRRATIO> Volts
:[SOURce:]VOLTage3 <n>
sets Output VOLTAGE ФC
n = <0> to <150, or 150 x XFMRRATIO> Volts
:[SOURce:]FREQuency <n>
sets Output Frequency
n = <:SOUR:FREQ:LIM:MIN> to <:SOUR:FREQ:LIM:MAX> Hz
Query Frequency display with :MEASure:FREQuency?
Returns the set value only. UPC does not measure Frequency
:[SOURce:]CURRent:LIMit <n>
sets Output Current Limit
n = <0> to <Current meter range> RMS Amps
:[SOURce:]CURRent:LIMit:MAX?
Query: returns <n>, the maximum current limit allowed based on
the present Form, Coupling and current transformer
:[SOURce:]IPROTect:STATe<b>
Enables Current Protect feature
b = <0>,<OFF> or <1>,<ON>
:[SOURce:]IPROTect:TRIPped?
Query: returns <n>
n = 1 if Current Protect has tripped (output disabled)
:[SOURce:]IPROTect:CLEar
Clears Current Protect fault register and associated counter
:[SOURce:]PHASe2 <n>
sets Output Ф angle B
n = <0> to <359> degrees
:[SOURce:]PHASe3 <n>
sets Output Ф angle C
n = <0> to <359> degrees
:[SOURce:]WAVEFORM <n>
sets Output Waveform, all phases
n = <1> to <16>
:[SOURce:]WAVEFORM1 <n>
sets Output Waveform ФA
n = <1> to <16>
:[SOURce:]WAVEFORM2 <n>
sets Output Waveform ФB
n = <1> to <16>
:[SOURce:]WAVEFORM3 <n>
sets Output Waveform ФC
n = <1> to <16>
