Chapter 5 Safety equipment
2 - Crane picture
The crane is displayed depending on its equipment. The following symbols are possible:
Representation of extension boom for crane without fly
jib.
Symbol for crane with fly jib
The arrows in the main display indicate which crane movements are currently possible If all
movements are possible, no arrows are displayed.
3 - Capacity indicator for 2nd fly jib (only for cranes with 2nd fly jib)
Capacity of 2nd fly jib in % of valid load limit.
4 - Charge status of battery in transmitter
4-stage indicator in steps of 25 %.
Charge status more than 75 %
Charge status more than 50 %
Charge status more than 25 %
Charge status less than 25 %
5 - Workman basket
The crane is in workman basket operating mode or material basket mode. Key switch is set to
basket operation.
6 - Radio signal strength
4-stage indicator in steps of 25 %.
Signal strength more than 75 %
Signal strength more than 50 %
Signal strength more than 25 %
Signal strength less than 25 %
