Panasonic AG-CX350

– 174 –
Chapter 7 Output and Screen Display — Screen status display
When P2 or MOV is set as the recording format, the audio channel displayed in the audio level meter follows the setting in the [AUDIO] menu →
[OUTPUT SETTINGS] → [AUDIO OUT].
f Displays the audio channel 1 and audio channel 2 when set to [CH1]/[CH2]/[CH1/2 STEREO]/[CH1/2 MIX].
f Displays the audio channel 3 and audio channel 4 when set to [CH3]/[CH4]/[CH3/4 STEREO]/[CH3/4 MIX].
f Switches the audio channel to display in the audio level meter (audio channel 1/2 and audio channel 3/4) while the USER button to which [AUDIO
MON SEL] is assigned is pressed or the USER button icon is touched.
Item Description
[AUDIO] [AUDIO OUT] Displays the audio channel and the format output from the <AV OUT> terminal,
headphone terminal, and the built-in speaker with [CH1]/[CH2]/[CH1/2
STEREO]/[CH1/2 MIX]/[CH3]/[CH4]/[CH3/4 STEREO]/[CH3/4 MIX].
[SELECT] [CH1] - [CH4] The audio to be recorded in each channel is displayed with [INT(L)]/[INT(R)]/
[INPUT1]/[INPUT2].
[LINE/MIC] [CH1] - [CH4] The audio input signal of each channel is displayed with [LINE]/[MIC]/
[MIC+48V].
Displays [---] when [INT(L)] or [INT(R)] is selected as the audio to be recorded.
[LEVEL] [CH1] - [CH4] Displays the adjustment method of the recording level of the audio for each
channel with [AUTO]/[MANU].
[LIMITER] [CH1] - [CH4] Displays enable/disable of limiter for each channel with [ON]/[OFF].
Displays [---] when the adjustment method of the recording level of the audio is
set to [AUTO].
[LOWCUT] [CH1] - [CH4] Displays enable/disable of low-cut lter for each channel with [ON]/[OFF].
SWITCH screen
Displays the function assigned to the USER switch, <GAIN> switch, and <WHITE BAL> switch as well as the setting value.
Item Description
[USER SW] [1] - [7] Displays the function assigned to <USER 1> through <USER 7> buttons.
[OTHER ASSIGN] [GAIN L] Displays the gain value assigned to the <L> position of the <GAIN> switch.
[GAIN M] Displays the gain value assigned to the <M> position of the <GAIN> switch.
[GAIN H] Displays the gain value assigned to the <H> position of the <GAIN> switch.
[S.GAIN] Displays the list of gain values assigned as a super gain.
It is not displayed when the [CAMERA] menu → [SW MODE] → [GAIN/ISO
MODE] is set to [ISO].
[WHITE BAL A] Displays the color temperature assigned to the <A> position of the <WHITE
BAL> switch.
Displays [ATW] when the auto tracking white balance function is assigned.
[WHITE BAL B] Displays the color temperature assigned to the <B> position of the <WHITE
BAL> switch.
Displays [ATW] when the auto tracking white balance function is assigned.
[WHITE BAL PRST] Displays the color temperature assigned to the <PRST> position of the
<WHITE BAL> switch.
Displays [ATW] when the auto tracking white balance function is assigned.
Color temperature and [VAR] are displayed when [VAR] is assigned.
NETWORK screen
Displays the settings of the network function.
Item Description
[NETWORK] [DEVICE SEL] Displays the device that connects an external equipment (computer, etc.) and
the camera with [LAN]/[WLAN]/[OFF].
[NETWORK FUNC]
Displays the network function of the camera with [STREAMING]/[NDI|HX]/
[OFF].
[STRM FORMAT] Displays the streaming format.
It is not displayed when set to the [NETWORK] menu → [NETWORK FUNC]
→ [OFF].
[STRM DATA TYPE] Displays the type of the streaming connection information.
It is not displayed when set to anything other than the [NETWORK] menu →
[NETWORK FUNC] → [STREAMING].
[IP REMOTE] Displays enable/disable of the IP remote function with [ENABLE]/[DISABLE].
[IPv4 ADDRESS] Displays the IP address of IPv4.
It is not displayed when set to the [NETWORK] menu → [DEVICE SEL] →
[OFF].
[IPv6 ADDRESS] Displays the IP address of IPv6.
[DISABLE] is displayed when the [NETWORK] menu → [LAN PROPERTY] →
[IPv6 SETTING] → [ENABLE/DISABLE] → [DISABLE] is set.
It is not displayed when set to anything other than the [NETWORK] menu →
[DEVICE SEL] → [LAN].
